ZJK150DPU edge board/flat board/U board production line

  • Product description: ZJK150DPU edge board/flat board/U board production line
  • INQUIRY
1.It could produce L edge board, U board and flat board.
2.If you want to change the produce of different type board, it just need change the forming wheels.
3.It adopts air cylinder to adjust the pressure.
4.It is convenient to control the machine with touch screen and servo system. The cut off precision is 1000±1mm.
5.It is safe to control and maintain the machine with the alarm and the fault display on the touch screen.

6.It could see the output on the touch screen.

Size of edge board 25~120mm
Thickness of edge board 2.5~10mm
Size of U board (inner width)15~150mm, (height)100mm
Thickness of U board 2.5mm~8mm
Size of flat board 50~180mm
Thickness of flat board 2.5~8mm
Speed edge board: 0~30m/min
U board:0~18m/min
flat board:0~30m/min
Cut off precision 1000±1mm
Max.layers 13(layers)
GSM of paper (surface paper)175~250gsm(kraft paper)
(inner paper) 420~600gsm (bobbin paper)
Total power 12.25KW
Dimension 25000×1400×1925mm
Total weight 5800KG
